Резонатор.ABM8G-12.000Mhz-18-D2Y
Электроэлемент
CRYSTAL, 12MHZ, 18PF, 3.2 X 2.5MM, Frequency Nom:12MHz, Crystal Case:SMD, 3.2mm x 2.5mm, Frequency Stability + / -:30ppm, Load Capacitance:18pF, Frequency Tolerance + / -:20ppm, Product Range:ABM8G Series, Crystal Mounting Type:SMD , RoHS Compliant: YesТехнические параметры
| 3D Model | ABM8G.pdfABM8G.stp |
| Category | Crystals and Oscillators |
| ESR (Equivalent Series Resistance) | 120 Ohm |
| Family | Crystals |
| Featured Product | ABM8G Series SMD Crystals |
| Frequency | 12MHz |
| Frequency Stability | ±30ppm |
| Frequency Tolerance | ±20ppm |
| Height | 0.039"(1.00mm) |
| Load Capacitance | 18pF |
| Mounting Type | Surface Mount |
| Online Catalog | ABM8G Series |
| Operating Mode | Fundamental |
| Operating Temperature | -40°C ~ 85°C |
| Other Names | 535-10261-2ABM8G12000MHZ18D2YT |
| Package / Case | 4-SMD, No Lead(DFN, LCC) |
| Packaging | Tape & Reel(TR) |
| Ratings | - |
| RoHS Information | RoHS2/REACH Compliance |
| Series | ABM8G |
| Size / Dimension | 0.126" L x 0.098" W(3.20mm x 2.50mm) |
| Standard Package | 1 |
| Type | MHz Crystal |
| Длина | 3.2мм |
| Тип корпуса | SMD |
| Standard Frequency | 12MHz |
| Series Resistance | 120Ω |
| Brand | Abracon |
| Dimensions | 3.2 x 2.5 x 1mm |
| Pin Count | 4 |
| Максимальная рабочая температура | 85°C |
| Minimum Operating Temperature | -40°C |
| Width_SC_PC | 2.5mm |
| Вес, г | 0.09 |
340.0 ₽
Наличие по запросу
